The A.P.D.
180 Degree Pallet Inverter
For Manufacturing and Warehouse distribution. We build to suit your needs.
We build to customer requirments or from our standard multi-purpose unit if required. Our standard unit is supplied to invert Euro pallets load heights of 2.0m with closing height of 700mm.
We build ground level units for pallet truck access as well forklift loading. Load transfer from wooden to plastic.
Reduce handling of heavy bags.
Easy to operate supplied with Hand Lever control or wall mounted panel.
Supplied enclosed in guarding surround with gate and electrical interlock.
Optional light curtain can be installed to elimate manual and technical file.
Pallet Specifications
Max. Load 1500kg
Max. Open height 2500mm
Max. Operating Diameter 2300mm
Max. Load height 2000mm
Min. Load Height 700mm
Total Width 2000mm
Jaw Width 2000mm
Jaw Depth 1200mm
Overall Depth 2200mm
Power Rating 3kw 3P
